    Product Details:

    Contact Now
    Detailed Product Description
    Standard: ISO12176-2 Data Input: Manual Input By Keypad Or Bar Code Scannin
    Control Model: Constant Voltage,constant Current,constant Power Voltage: AC110~240V;3AC350~450V
    Powwe: 3.5KW;8KW;12KW;15KW;22KW

    PE electrofusion welding machine for pe pipe

    electro fusion hdpe fitting welder

    Gas and water polyethylene (PE) pipes and fittings welding equipment

    electrofusion hdpe fitting welder



    Advantage and application:

    DPS10series electrofusion welding machine using true RMS control, is mainly used in connection of

    gas or water polyethylene (PE) pipes and fittings. It is the perfect corollary equipment for every PE pipe,

    pipe fitting manufactures and construction units.

    The machine has higher performance than the international standard ISO12176-2 in welding voltage

    stability, welding time accuracy and the temperature detection accuracy, etc.



    Features:

    1.Advanced MCU as control unit, with abundant parameter settings, detection and perfect protection,

    2. Fast response to sudden power change (500 ~ 800ms), excellent stability,

    3.Wide voltage Input: AC170V - 270V, adapt to site grid,

    4.High brightness LCD display, Chinese or English operation, user-friendly HMI,

    5.Output voltage / current / heat, past welding time / remaining time, welding status,

    browser on any input data,

    6.Suppression of harmonic output,

    7.Protection of cable moving parts with flexible connection,

    8.IP rating 54, guaranteed normal use in harsh environment.



    Specifications:

    Input

    Voltage/Frequency

    (1AC220,1AC380V,3AC380) -10%~+20%   4565Hz

    Index

    Voltage stability

    Better than 0.25%

    Time resolution

    Better than±0.01%

    Current stability

    Better than 0.5%

    Temp. resolution

    ±0.5℃

    Energy stability

    Better than 0.5%

    Load sustained rate

    80%

    Others

    Data input

    Manual input by keypad or bar code scanning.

    Programmable

    10 step programmable welding function, suitable for requirements of different pipes

    HMI

    High-brightness LCD display, user-friendly

    Data storage

    500 entries of records

    Protection against

    Input voltage fault, output overvoltage or undervoltage, overload, short circuit, frequency fault, etc.

    Cooling

    Fan cooling

    Dimensions

    Height×width×depth: 380mm×242mm×487mm



    CANEX - DPS10 Series Plastic Pipe Welder  dn20-1200mm electrofusion welding machine






    PE fitting Electro fusion welding Machine




    IEFD3.5KW HDPE Automatic Electro Fusion Machine

    CANEX - IEFD Series Plastic Pipe Welder -Elecrofusion welding machine






    CANEX - IEFT Series Plastic Pipe Welder -Elecro Fusion welding machine HDPE






    HDPE Electrofusion machine




    Electrofusion welding machine for PE pipe fitting






    Electrofusion welding machine for plastic pipes and fittings






    For more details on electrofusion welding machine, please feel free to contact us :
